IM 1287-6 • REBEL APPLIED ROOFTOP 52 www.DaikinApplied.com

Figure 95: Damper Adjustment
Return Section
Outdoor Air Damper
Damper Actuator
Damper Actuator
Manual Override
(adjusted with
Allen key,
provided with
unit)
