Figure 138: Wiring Raceway, Air Handler Sections
Figure 139: Wiring Connections Control Box (located in Condenser Section, Shown without Doors or Panels)
Wiring raceway (remove cover for access to
harnesses from main control box to unit-
mounted control devices)
Wiring entrance point from air
handler sec�on
Wiring entrance point
to main control box
from outside of unit
Wiring entrance
point to low
voltage control box
Wiring entrance point for
condenser fan wires
