Daikin REQ71B8V3B - External Connection Diagram

1
9
• Split Sky Air • Outdoor Units
30
• Outdoor Units • R-410A • REQ-B8V3B_REQ-B8W1B
9 Wiring diagram
9 - 2 External connection diagram
4TW26329-7
REQ71∼125B
Field wire
Symbol explication
I = Pair
II = Twin
III = Triple
M = Master
S = Slave
1 = Earth leak detector
2 = Fuse
3 = Remote control
