Daikin REQ71B8V3B - Electrical Specifications

1
2
• Split Sky Air • Outdoor Units
8
• Outdoor Units • R-410A • REQ-B8V3B_REQ-B8W1B
2 Specifications
Piping
connections
Liquid (OD)Quantity 11111
Type Flare connection
Diameter
(OD)
mm 9.52 9.52 9.52 9.52 9.52
GasQuantity 11111
Type Flare connection
Diameter
(OD)
mm 15.9 15.9 15.9 15.9 15.9
Drain Quantity 3 3 3 3 3
Type Hole
Diameter
(OD)
mm 26 26 26 26 26
Piping Length Minimum m 5 5 5 5 5
Maximum m 50 50 50 50 50
Equivalent m 70 70 70 70 70
Chargeless m 7.5 7.5 7.5 7.5 7.5
Installation
height
difference
Maximum m 30.0 30.0 30.0 30.0 30.0
Max. internunit level
difference
m 0.5 0.5 0.5 0.5 0.5
Heat Insulation Both liquid and gas pipes
Defrost Method Reversed cycle
Defrost Control Sensor for outdoor heat exchanger temperature
Capacity Control Method None
Safety Devices Reverse phase protector
PC board fuse
Overcurrent relay (compressor)
Low pressure switch
High pressure switch
Fan motor thermal protector
Standard
Accessories
Item Declaration of conformity
Quantity 1 1 1 1 1
Item Installation manual
Quantity 1 1 1 1 1
Notes Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
Sound values are measured in a semi-anechoic room.
In case of drain piping for outdoor unit, drain piping kit (option) is needed.
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
2-3 ELECTRICAL SPECIFICATIONS REQ71B8V3B REQ71B8W1B REQ100B8V3B REQ100B8W1B REQ125B8W1B
Power Supply Name V3 W1 V3 W1 W1
Phase 1 3N 1 3N 3N
Frequency Hz 50 50 50 50 50
Voltage V 230 400 230 400 400
Voltage range Minimum V -10%
Maximum V +10%
Current
Recomended fuses A 32 16 40 16 20
Wiring
connections
For Power
Supply
Quantity 11111
Remark 3 wires (earth wire
included)
5 wires (earth wire
included)
3 wires (earth wire
included)
5 wires (earth wire
included)
5 wires (earth wire
included)
For connection
with indoor
Quantity 11111
Remark 4 wires (earth wire included)
Power Supply Intake Outdoor unit only
2-2 TECHNICAL SPECIFICATIONS REQ71B8V3B REQ71B8W1B REQ100B8V3B REQ100B8W1B REQ125B8W1B
