Daikin REQ71B8V3B - Page 7

• Outdoor Units • R-410A • REQ-B8V3B_REQ-B8W1B
1
2
• Split Sky Air • Outdoor Units
7
2 Specifications
Heat
Exchanger
Dimensions Length mm 857 857 857 857 857
Nr of Rows 2 2 2 2 2
Fin Pitch mm 2.00 2.00 2.00 2.00 2.00
Nr of Passes 6 6 10 10 10
Face Area m² 0.641 0.641 0.980 0.980 0.980
Nr of Stages 34 34 52 52 52
Tube type Hi-XSS cooling tube
Fin Type Non-symmetric waffle louvre
Treatment Anti-corrosion treatment (PE)
Fan Type Direct Drive Propeller
Discharge direction Horizontal
Quantity 11112
Air Flow Rate
(nominal at
230V)
Cooling m³/min 48.0 48.0 55.0 55.0 89.0
Heating m³/min 43.0 43.0 50.0 50.0 80.0
Motor Quantity 1 1 1 1 1
Model P47L11S
Position Lower
Motor Speed
(nominal)
Steps 33333
Fan Motor Output W 65 65 90 90 85
Position Upper
Motor Speed
(nominal)
Steps 3
Fan Motor Output W 65
CompressorQuantity 11111
Motor Model JT90G-P4V1N@S JT90G-YE JT125G-P4V1@S JT125G-YE JT160G-YE
Type Hermetically sealed scroll compressor
Motor
Output
W 2200 2200 3000 3000 3750
Crankcase
Heater
W3333333333
Operation
Range
Cooling Min °CDB 10.0 10.0 10.0 10.0 10.0
Max °CDB 46.0 46.0 46.0 46.0 46.0
Heating Min °CWB -10 -10 -10 -10 -10
Max°CWB1515151515
Sound Level
(nominal)
Cooling Sound
Power
dBA 65.0 65.0 70.0 70.0 70.0
Sound
Pressure
dBA 53.0 53.0 57.0 57.0 57.0
Refrigerant Type R-410A
Charge kg 2.5 2.5 3.6 3.6 3.6
Control Expansion valve (electronic type)
Nr of Circuits 11111
Refrigerant Oil Type Daphne FVC68D
Charged Volume l 1.5 1.5 1.5 1.5 1.5
2-2 TECHNICAL SPECIFICATIONS REQ71B8V3B REQ71B8W1B REQ100B8V3B REQ100B8W1B REQ125B8W1B
