Si001156
Removal of
Outer Panels / Fa
n Motor
Remo
val P
roced
ure
9
2
Remove the 4 screws
on the ri
ght si
de panel.
3
Remove the screw near
the st
op valves
.
4
Unfasten t
he hook on
the rear
side.
When reassembling,
make
sure t
o fit
the hook.
Step
Procedure
Points
(R12163)
Right side panel
(R11839)
(R11842)
10
12
Table of Contents
Table of Contents
3
Removal of Outer Panels / Fan Motor
4
Removal of Electrical Box
13
Removal of Pcbs
16
Removal of Reactor / Partition Plate
23
Removal of Sound Blankets
25
Removal of Four Way Valve
27
Removal of Compressor
30
