Removal of Rea
ctor / Partition Pla
te
Si001156
22
Removal Proc
edure
2
The parti
ti
on plat
e has
2 hooks on the l
ower
side.
Li
ft and pul
l the
parti
ti
on plat
e to
rem
ove.
When reassembling,
fi
t the
lower hook
s int
o the bot
tom
frame.
Step
Procedure
Points
(R13508)
Hook
23
25
