Si001156
Removal of
Outer Panels / Fa
n Motor
Remo
val P
roced
ure
7
7
Remove the screw and
remove the f
an m
otor
fix
ing f
rame.
When reassembling,
fi
t the
lower hook
s int
o the bot
tom
frame.
Step
Procedure
Points
(R11833)
F
an motor fixing frame
(R12314)
(R7206)
8
10
Table of Contents
