Daikin RN10FV1 - Dimensional Data; Indoor Unit - FTL & FTM Series

41
TM-FT-0415-B
9.DimensionalData
Indoor Unit - FTL & FTM Series
FTNP & FTNM Series
All dimensions are in mm
Dimension
Model
A B C D E F G H I J K L M
FT10/15LV1L
FT10/15LV1M
FTN10/15PV1L
FTN10/15PV1M
800 288 166 184 42 46 55 56 154 182 263 52
206
212
A
THE MARK SHOWS PIPING DIRECTION
LEFT
REAR
TOP VIEW
REAR
RIGHT
B
BOTTOM
LOUVER
FRONT GRILLE FIXED SCREWS
(INSIDE)
BOTTOM
FRONT VIEW
SIGNAL RECEIVER
INDOOR UNIT
ON/OFF SWITCH
ROOM TEMPERATURE
THERMISTOR (INSIDE)
B
NAME PLATE
TERMINAL
BLOCK WITH
EARTH
TERMINAL
C
SIDE VIEW
etalp gnitnuom dednemmoceR
retention spots (5 spots in all)
D
Use tape measure as shown.
Position the end of a tape
measure at
B
G
H J
L
M
A
K
F
I
G
F
E
Through the wall
hole Ø 65mm
Drain hose position
Gas pipe endLiquid pipe end
INSTALLATION PLATE : FT10/15LV1L, FT10/15LV1M & FT10/15MV1L, FT10/15MV1J
FTN10/15PV1L, FTN10/15PV1M & FTN10/15MV1I9, FTN10/15MV1J9
FT10/15MV1I
FT10/15MV1J
FTN10/15MV1I9
FTN10/15MV1J9
800 288 216 166 184 42 46 55 56 154 182 263 52
