Si011084 Removal of Outer Panels
Removal Procedure 3
3 Remove the 6 screws
of the front panel.
4 Unfasten the center
hooks in the order of (1)
to (2).
5 Lift the left side of the
front panel and
unfasten the 3 hooks.
Step Procedure Points
(R5395)
(R13614)
(1)
Hook
(R5397)
