1.3 Additional Refrigerant Charge Procedure
Charge the additional refrigerant by following procedure before test operation.
Calculation of refrigerant amount
Connection of devices for
refrigerant charge
Additional charging of refrigerant
(precharge)
(Refer to p.131)
Provide the calculated additional refrigerant amount as “G”
(Refer to 1.3.1)
If automatic charging of
refrigerant is not necessary
(Refer to 1.3.2)
Charge (G – 10kg)
Additional charging of refrigerant
(Refer to 1.3.2)
Fill “G” volume
Operate additional charging to
remaining refrigerant
(Refer to 1.3.5)
Automatic refrigerant charging operation (Refer to 1.3.3)
*1
Heating mode (manual operation) Cooling mode (automatic operation)
Automatic charging completed
*1
Outdoor temperature: 0 – 43°CDB
Indoor temperature: 10 – 32°CDB
Temperature below the above range
Operate in
cooling mode
Operate in
heating mode
(Detecting refrigerant leakage; required)
Press BS 4 button once to detect refrigerant leakage
(Detecting refrigerant leakage; not required)
Press BS 1 button once to complete charging
Record the amount of additional refrigerant charging on “Record plate for additional charging”
Input the additional refrigerant charge
weight into the PCB
Check operation
(Refer to 1.3.4)
(Refer to 1.4)
