Daikin RTSQ14PY1 User Manual

Model Selection SiBE31-801_C
5 General Information
3. Model Selection
VRV III-C Heat Pump Series
Connectable indoor units number and capacity
Connectable Indoor Unit
Note: FXDQ has following 2 Series, as show below.
FXDQ-PB, NBVE: with Drain Pump
BEV unit is required for FXUQ only.
MA: RoHS Directive models; Specifications, Dimensions and other functions are not changed compared with
M type.
HP 10HP 14HP 16HP 20HP
System name RTSYQ10PY1 RTSYQ14PY1 RTSYQ16PY1 RTSYQ20PY1
Outdoor unit 1 RTSQ10PY1 RTSQ14PY1 RTSQ16PY1 RTSQ8PY1
Outdoor unit 2 – – – RTSQ12PY1
Function unit BTSQ20PY1 BTSQ20PY1 BTSQ20PY1 BTSQ20PY1
Total number of connectable
indoor units
16 22 26 32
Total capacity of connectable
indoor units (kW)
14.0~36.4 22.0~52.0 22.5~58.5 28.0~72.8
Type Model Name
Power
Supply
Roundflow Ceiling
Mounted Cassette
FXFQ 20P8 25P8 32P8 40P8 50P8 63P8 — 80P8 100P8 125P8 ——— VEB
600×600 4-Way Blow
Ceiling Mounted
Cassette
FXZQ20M925M932M940M950M9———————— V1B
2-Way Blow Ceiling
Mounted Cassette
FXCQ 20M8 25M8 32M8 40M8 50M8 63M8 — 80M8 — 125M8 ——— V3B
Ceiling Mounted
Corner Cassette
FXKQ — 25MA 32MA 40MA — 63MA ———————
VE
Slim Concealed Ceiling
Unit
FXDQ-
PBVE
20PB25PB32PB——————————
FXDQ-
NBVE
———40NB50NB63NB———————
Concealed Ceiling Unit
(Small)
FXDQ20M925M9——————————— V3B
Concealed Ceiling Unit
FXSQ 20P7 25P7 32P7 40P7 50P7 63P7 — 80P7 100P7 125P7 ——— VEB
Concealed Ceiling Unit
FXMQ 20P 25P 32P 40P 50P 63P — 80P 100P 125P 140P — —
VE
Concealed Ceiling Unit
(Large)
FXMQ——————————— 200MA 250MA
Ceiling Suspended Unit
FXHQ — — 32MA —— 63MA —— 100MA ————
Wall Mounted Unit
FXAQ20P25P32P40P50P63P——————— V1
Floor Standing Unit
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA ———————
VE
Concealed Floor
Standing Unit
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA ———————
Outdoor Air Processing
Unit
FXMQ-
MF
—————————
125MF — 200MF 250MF
V1
4-way blow ceiling
suspended unit
FXUQ—————— 71MA — 100MA 125MA ———
Connection Unit for
FXUQ
BEVQ —————— 71MA — 100MA 125MA ——— VE
