11 | Configuration
Installer reference guide
57
ARXM50-71+RXM42~71R2V1B + RXP50~71M2V1B + RXA42+50B2V1B +
RXF50+60B2V1B + RXF71A2V1B + RXJ50N2V1B + ARXF50~71A2V1B
R32 split series
4P513661-9J – 2020.05
INFORMATION
The standby electricity saving can ONLY be used for the units described above.
WARNING
Before connecting or disconnecting the connector, make sure the power supply is
turned off.
INFORMATION
Selective connector for standby electricity saving is required if other than applicable
indoor unit is connected.
11.2.2 To turn on standby electricity saving function
Prerequisite: The main power supply MUST be turned off.
1 Remove the service cover.
2 Disconnect the selective standby electricity saving connector.
3 Turn on the main power supply.
