Appendix SiEN34-705
174 General Information
7.12.1.2 Heat Pump 60Hz
RXYQ5PYL
3D055764A
Filter
Filter
Filter
Filter
Filter
Filter
Stop valve (with service port ø7.9mm flare connection)
Capillary tube
Solenoid
valve
Solenoid
valve
Check valve
Accumulator
Electronic
expansion valve
Four way
valve
Pressure
regulating valve
(check valve type)
HPS
COMPRESSOR
INV
SENPL
OIL
SEPARAToR
High pressure
switch
Solenoid
valve
Capillary tube
High pressure
sensor
Low pressure
sensor
Capillary tube
Heat
exchanger
