Daikin RXQ8PY1 - Introduction

SiEN34-705 Heat Pump 60Hz (RXYQ5~54P)
Installation Manual 265
2.2 Introduction
! RXYQ-P series are designed for outdoor installation and used for cooling and heatpump
applications. Outdoor units come in three standard sizes, and with a single system through a
multi system combining up to three outdoor units, rated cooling capacity from 14.0 kW to 147
kW and rated heating capacity from 16.0 kW to 170 kW can be achieved.
! The RXYQ-P units can be combined with Daikin VRV series indoor units for air conditioning
purposes. Always use appropriate indoor units compatible with R-410A. To lean which
models of indoor units are compatible with R-410A, refer to the product catalogs.
To combine with other refrigerant indoor unit will cause malfunction.
2.2.1 Combination
The indoor units can be installed in the following range.
<Outdoor unit> <Total capacity of indoor units> <Total quantity of indoor units>
RXYQ5PYL(E) ................... 62.5 ~ 250 12 units
RXYQ8PYL(E) ................. 100 ~ 400 20 units
RXYQ10PYL(E) .............. 125 ~ 500 25 units
RXYQ12PYL(E) ............... 150 ~ 600 30 units
RXYQ14PYL(E) ............... 175 ~ 700 35 units
RXYQ16PYL(E) ............... 200 ~ 800 40 units
RXYQ18PYL(E) ............... 225 ~ 900 45 units
RXYQ20PYL(E) ............... 250 ~ 800 40 units
RXYQ22PYL(E) ............... 275 ~ 880 44 units
RXYQ24PYL(E) ............... 300 ~ 960 48 units
RXYQ26PYL(E) ............... 325 ~ 1040 52 units
RXYQ28PYL(E) ............... 350 ~ 1120 56 units
RXYQ30PYL(E) ............... 375 ~ 1200 60 units
RXYQ32PYL(E) ............... 400 ~ 1280 64 units
RXYQ34PYL(E) ............... 425 ~ 1360 64 units
RXYQ36PYL(E) ............... 450 ~ 1440 64 units
RXYQ38PYL(E) ............... 475 ~ 1235 61 units
RXYQ40PYL(E) ............... 500 ~ 1300 64 units
RXYQ42PYL(E) ............... 525 ~ 1365 64 units
RXYQ44PYL(E) ............... 550 ~ 1430 64 units
RXYQ46PYL(E) ............... 575 ~ 1495 64 units
RXYQ48PYL(E) ............... 600 ~ 1560 64 units
RXYQ50PYL(E) ............... 625 ~ 1625 64 units
RXYQ52PYL(E) ............... 650 ~ 1690 64 units
RXYQ54PYL(E) ............... 675 ~ 1755 64 units
Note: ! Be sure to connect an R-410A indoor unit.
See the catalog for indoor unit models which can be connected.
! At above is the total capacity and total number of units of the indoor units when configured in
a standard combination. See the technical reference for details on total capacity and total
number of indoor units when using a configuration other than the standard combination. The
standard combination are as follows.
