2.2.4 Technical and Electrical Specifications
Refer to the Engineering Data Book for the complete list of specifications.
2.2.5 Main Components
For main components and function of the main components, refer to the Engineering Data
Book.
2.2.6 Installation Process
Figure 2 shows the installation process. Install in the order of the steps shown.
figure 2
“2-11 Additional Refrigerant
Charge and Check Operation”
Operations which require the
power to be turned on.
“2-8 Air Tight Test and
Vacuum Drying”
“2-4 Inspecting and
Handling the Unit”
“2-3 Selection of Location”
“2-5 Placing the Unit”
“2-7 Field Wiring”
“2-6 Refrigerant Piping”
“2-9 Pipe Insulation”
“2-13 Test Run”
“2-10 Checking of Device and
Installation Conditions”
To Next Page
