Capacity Tables EDUS121131
210 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
3D078924 ~ 3D078929
3D078930 ~ 3D078939
3D078940 ~ 3D078949
3D078950 ~ 3D078951
CTXS09H +
CTXS12H +
FDXS12L +
FDXS12L
60.8 18.96 2.61 22.78 2.74 26.60 2.87 30.41 3.01 34.99 3.17 38.05 3.27 41.86 3.41
64.4 18.50 2.63 22.31 2.77 26.13 2.90 29.95 3.03 34.53 3.19 37.58 3.30 41.40 3.43
68.0 18.03 2.66 21.85 2.80 25.66 2.93 29.48 3.06 34.06 3.22 37.11 3.33 40.93 3.46
70.0 17.77 2.68 21.59 2.81 25.40 2.95 29.22 3.08
33.80 3.24 36.85 3.35 40.67 3.48
71.6 17.56 2.69 21.38 2.83 25.20 2.96 29.01 3.09 33.59 3.25 36.65 3.36 40.46 3.49
75.2 17.10 2.72 20.91 2.86 24.73 2.99 28.55 3.12 33.13 3.28 36.18 3.39 40.00 3.52
CTXS09H +
FDXS12L +
FDXS12L +
FDXS12L
60.8 18.68 2.65 22.44 2.79 26.20 2.93 29.96 3.06 34.47 3.22 37.48 3.33 41.24 3.47
64.4 18.22 2.68 21.98 2.82 25.74 2.95 29.50 3.09 34.02 3.25 37.02 3.36 40.78 3.50
68.0 17.76 2.71 21.52 2.85 25.28 2.98 29.04 3.12 33.56 3.28 36.56 3.39 40.32 3.53
70.0 17.51 2.73 21.27 2.87 25.03 3.00 28.79 3.14
33.30 3.30 36.31 3.41 40.07 3.54
71.6 17.30 2.74 21.06 2.88 24.82 3.01 28.58 3.15 33.10 3.31 36.10 3.42 39.86 3.56
75.2 16.84 2.77 20.60 2.91 24.36 3.04 28.12 3.18 32.64 3.34 35.64 3.45 39.40 3.59
FDXS09L +
CTXS12H +
CTXS12H +
CTXS12H
60.8 19.19 2.57 23.05 2.70 26.91 2.84 30.77 2.97 35.41 3.13 38.50 3.23 42.36 3.36
64.4 18.71 2.60 22.58 2.73 26.44 2.87 30.30 3.00 34.93 3.16 38.02 3.26 41.89 3.39
68.0 18.24 2.63 22.10 2.76 25.97 2.89 29.83 3.03 34.46 3.18 37.55 3.29 41.41 3.42
70.0 17.98 2.65 21.84 2.78 25.70 2.91 29.57 3.04
34.20 3.20 37.29 3.31 41.15 3.44
71.6 17.77 2.66 21.63 2.79 25.49 2.92 29.36 3.05 33.99 3.21 37.08 3.32 40.94 3.45
75.2 17.30 2.69 21.16 2.82 25.02 2.95 28.88 3.08 33.52 3.24 36.61 3.35 40.47 3.48
FDXS09L +
CTXS12H +
CTXS12H +
FDXS12L
60.8 18.96 2.61 22.78 2.74 26.60 2.87 30.41 3.01 34.99 3.17 38.05 3.27 41.86 3.41
64.4 18.50 2.63 22.31 2.77 26.13 2.90 29.95 3.03 34.53 3.19 37.58 3.30 41.40 3.43
68.0 18.03 2.66 21.85 2.80 25.66 2.93 29.48 3.06 34.06 3.22 37.11 3.33 40.93 3.46
70.0 17.77 2.68 21.59 2.81 25.40 2.95 29.22 3.08
33.80 3.24 36.85 3.35 40.67 3.48
71.6 17.56 2.69 21.38 2.83 25.20 2.96 29.01 3.09 33.59 3.25 36.65 3.36 40.46 3.49
75.2 17.10 2.72 20.91 2.86 24.73 2.99 28.55 3.12 33.13 3.28 36.18 3.39 40.00 3.52
FDXS09L +
CTXS12H +
FDXS12L +
FDXS12L
60.8 18.68 2.65 22.44 2.79 26.20 2.93 29.96 3.06 34.47 3.22 37.48 3.33 41.24 3.47
64.4 18.22 2.68 21.98 2.82 25.74 2.95 29.50 3.09 34.02 3.25 37.02 3.36 40.78 3.50
68.0 17.76 2.71 21.52 2.85 25.28 2.98 29.04 3.12 33.56 3.28 36.56 3.39 40.32 3.53
70.0 17.51 2.73 21.27 2.87 25.03 3.00 28.79 3.14
33.30 3.30 36.31 3.41 40.07 3.54
71.6 17.30 2.74 21.06 2.88 24.82 3.01 28.58 3.15 33.10 3.31 36.10 3.42 39.86 3.56
75.2 16.84 2.77 20.60 2.91 24.36 3.04 28.12 3.18 32.64 3.34 35.64 3.45 39.40 3.59
FDXS09L +
FDXS12L +
FDXS12L +
FDXS12L
60.8 18.46 2.72 22.17 2.86 25.89 3.00 29.60 3.14 34.06 3.30 37.03 3.41 40.75 3.55
64.4 18.00 2.75 21.72 2.89 25.43 3.03 29.15 3.17 33.61 3.33 36.58 3.44 40.29 3.58
68.0 17.55 2.78 21.26 2.92 24.98 3.06 28.69 3.20 33.15 3.36 36.12 3.47 39.84 3.61
70.0 17.30 2.80 21.01 2.93 24.73 3.07 28.44 3.21
32.90 3.38 35.87 3.49 39.59 3.63
71.6 17.10 2.81 20.81 2.95 24.53 3.09 28.24 3.23 32.70 3.39 35.67 3.50 39.39 3.64
75.2 16.64 2.84 20.36 2.98 24.07 3.12 27.79 3.26 32.24 3.42 35.22 3.54 38.93 3.67
Combination
(Capacity)
Indoor air
temp.
EDB (°F)
Outdoor air temp. EWB (°F)
5.0 14.0 23.0 32.0 43.0 50.0 59.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h
kW
kBtu/h
kW
kBtu/h
kW
kBtu/h
kW
kBtu/h
kW
kBtu/h
kW
kBtu/h
kW
Symbols: Note:
EWB : Entering wet bulb temp. (°F) 1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat.
2. shows nominal (rated) capacities and power input.
3. TC and PI must be calculated by interpolation using the figures in the
above tables. (Figures out of the tables should not be used for
calculation.)
4. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25 ft
EDB : Entering dry bulb temp. (°F)
TC : Total capacity (kBtu/h)
PI : Power input (kW)
