Electric Characteristics EDUS121131
218 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
11.Electric Characteristics
3D059055A
Outdoor Unit
Power Supply Comp. OFM
Hz Volts Min. Max. MCA MOP MSC RLA W FLA
2MXS18GVJU 60
208 187 229
11.1 20
9.1 8.5
53 0.26
230 207 253 8.3 7.7
3MXS24JVJU 60
208 187 229
17.8 20
13.3 11.7
66 1.02
230 207 253 12.0 10.4
4MXS32GVJU 60
208 187 229
18.0 20
15.3 13.6
66 1.02
230 207 253 13.8 12.1
Symbols: Note:
MCA : Min. circuit amps (A) 1. RLA is based on the following conditions.
Cooling
Indoor temp.: 80°FDB (27°CDB) / 67°FWB (19°CWB)
Outdoor temp.: 95°FDB (35°CDB)
2. Voltage range:
Units are suitable for use on electrical systems where voltage
supplied to unit terminal is not below or above listed range limits.
3. Maximum allowable voltage variation between phases is 2%.
4. MCA represents maximum input current.
MOP represents capacity which may accept MCA.
5. Select wire size based on the large value of MCA.
6. MOP is used to select the circuit breaker and the ground fault
circuit interrupter.
7. Be sure to install a ground leakage detector that can handle
higher harmonics. This unit uses an inverter, so it requires a
ground leakage detector capable of handling high harmonics in
order to prevent malfunctioning of the ground leakage detector .
MOP : Max. overcurrent protection (A)
MSC : Max. current during starting compressor (A)
RLA : Rated load amps (A)
OFM : Outdoor fan motor
W : Fan motor rated output (W)
FLA : Full load amps (A)
