13
Note: The water pressure drop curve is measured base on clean water, the water pressure drop measured at
site may be different because of different water quality.
Test condition: Octave band level noise is tested in noise chamber whose background noise level is
11.5dB(A), during actual use, due to environmental noise or other reasons, the real noise
may be different.
Acoustic Noise
Curve for water pressure drop of evaporator/condenser
UWL030B5 evaporator
UWL040B5 evaporator
UWL040B5 condenser
UWL030B5 condenser
Water ow (m
3
/h)
Water pressure drop (kPa)
Model
Octave Band Level (dB,ref20μPa) dB(A)
63Hz 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz Overall
UWL030B5 37.5 43.2 50.7 65.4 56.0 59.1 59.7 52.7 62.0
UWL040B5 46.3 53.6 60.6 66.4 65.7 62.9 58.6 51.6 65.0
Water pressure drop curve
Sound Data
