18 Centrifugal Chillers IM 1044-2
Table 6 Unit Weights, Dual Compressor, WDC/WCC
Unit
Evaporator / Condenser
Size
Max. Unit Weight Without Starter
Max. Unit Weight With Starter (Note 1)
Shipping
lbs. (kg)
Operating
lbs. (kg)
Shipping
lbs. (kg)
Operating
lbs. (kg)
WDC063
2416 / 2416
18673 (8470)
20422 (9263)
21407 (9710)
23156 (10503)
WDC063
2416 / 2616
19365 (8784)
21294 (9577)
22099 (10024)
23848 (10817)
WDC063
2616 / 2416
19282 (8746)
21207 (9639)
22016 (9986)
23763 (10779)
WDC063
2616 / 2616
20025 (9083)
22091 (9939)
22759 (10323)
24646 (11179)
WDC063
3016 / 3016
23545 (10680)
26405 (11830)
26279 (11920)
28815 (13070)
WDC063
3616 / 3016
27763 (12604)
31018 (14082)
30163 (13694)
33418 (15172)
WDC063
3616 / 3616
32027 (14540)
35115 (15942)
33427 (15176)
37515 (17032)
WDC079
3016 / 3016
25131 (11399)
27671 (12551)
27531 (12488)
30071 (13640)
WDC079
3616 / 3016
28763 (13047)
32018 (14523)
31163 (14135)
34418 (15612)
WDC079
3616 / 3616
32027 (14527)
36115 (16382)
34427 (15616)
38515 (17470)
WDC079
4216 / 4216
44470 (20189)
51463 (23364)
47204 (21431)
54197 (24605)
WDC087
3016 / 3016
26157 (11865)
28697 (13017)
28891 (13105)
31431 (14257)
WDC087
3616 / 3016
29789 (13512)
33044 (14989)
32523 (14752)
35778 (15322)
WDC087
3616 / 3616
33053 (14993)
37141 (16847)
35787 (16233)
39875 (18087)
WDC087
4216 / 4216
44470 (20189)
51463 (23364)
47204 (21431)
54197 (24605)
WDC100, 113
3616 / 3616
41816 (18967)
46513 (21098)
See Note 2
See Note 2
WDC100, 113, 126 (<7kV)
4216 / 4216
50470 (22893)
57463 (26065)
See Note 2
See Note 2
WDC100, 113, 126 (<7kV)
4816 / 4816
59185 (26846)
68996 (31296)
See Note 2
See Note 2
WDC100, 113, 126 (<7kV)
4220 / 4220
54802 (24858)
63248 (28689)
See Note 2
See Note 2
WDC100, 113, 126 (<7kV)
4820 / 4820
65964 (29921)
77698 (35243)
See Note 2
See Note 2
WCC100, 113, 126 (<7kV)
3620 / 3620
37645 (17091)
41334 (19268)
See Note 2
See Note 2
WCC100, 113, 126 (<7kV)
4220 / 3620
41320 (18759)
45609 (21317)
See Note 2
See Note 2
WCC100, 113, 126 (<7kV)
4220 / 4220
45314 (20573)
50281 (23767)
See Note 2
See Note 2
WCC100, 113, 126 (<7kV)
4820 / 4220
49759 (22590)
56173 (26305)
See Note 2
See Note 2
WCC100, 113, 126 (<7kV)
4820 / 4820
55927 (25391)
62528 (29876)
See Note 2
See Note 2
WDC100, 113, 126 (10/11kV)
4216/4216
55760 (25292)
63536 (28219)
See Note 2
See Note 2
WDC100, 113, 126 (10/11kV)
4220/4220
62136 (28184)
71426 (32398)
See Note 2
See Note 2
WDC100, 113, 126 (10/11kV)
4820/4820
73526 (33351)
86282 (39137)
See Note 2
See Note 2
WCC100, 113, 126 (10/11kV)
4220/4220
55987 (25395)
63262 (28695)
See Note 2
See Note 2
WCC100, 113, 126 (10/11kV)
4820/4820
65768 (29832)
75761 (34365)
See Note 2
See Note 2
Notes:
1. With starters (factory mounted) applies only to low voltage (200 to 600 volts) equipment.
