www.DaikinApplied.com 85 IOM 1322 • WATER-COOLED SCROLL COMPRESSOR
R410A
TEST UNIT (1)
TEST UNIT (2)
TEST UNIT (1)
TEST UNIT (3)
TEST UNIT (3)
TEST UNIT (4)
TEST UNIT (4)
TEST UNIT (5)
TEST UNIT (5)
TEST UNIT (6)
Editing shall be accomplished by pressing the ENTER key until
the desired eld is selected. This eld shall be indicated by a
blinking cursor under it. The arrow keys shall then operate as
dened below.
CANCEL (Right) Reset the current eld to the value it had
when editing began.
(Left) Set value to original factory setting.
INCREMENT (Up) Increase the value or select the next item
in a list.
DECREMENT (Down) Decrease the value or select the
previous item in a list.
During edit mode, the display shall show a two-character wide
menu pane on the right as shown below
SET UNIT SPs (X) <D
(data) <C
(data) <+
(data) <-
Additional elds can be edited by pressing the ENTER key until
the desired eld is selected. When the last eld is selected,
pressing the ENTER key switches the display out of “edit”
mode and returns the arrow keys to “scroll” mode.
Alarms
When an alarm occurs, the alarm type, limit value (if any), date,
and time are stored in the active alarm buer corresponding
to that alarm (viewed on the Alarm Active screens) and also
in the alarm history buer (viewed on the Alarm Log screens).
The active alarm buers hold a record of the last occurrence of
each alarm and whether or not it has been cleared. The alarm
can be cleared by pressing the Edit key. A separate buer is
available for each alarm (High Cond Pressure, Evaporator
Freeze Protect, etc.). The alarm history buer holds a
chronological account of the last 25 alarms of any type.
