Daintree GE Current WFA100-SN - Page 2

Installation GuideDaintree
®
Networked Wireless Fixture Adapter (WFA100-SN)
2
2 3
Occupancy Sensor Time Delays Wiring
IfanoccupancysensorisconnectedtotheWFA100-SN,
thetimedelaymustbesetforminimum.WhenDaintree
Networkediscommissioned,timedelaysaresetinthe
DaintreeDCSwebapplication.TheseDCS“Offdelays”start
countingdownafterthesensor’sinternaltimedelayexpires.
Therefore,settheoccupancysensorfortheminimumtime
delay during the WFA100-SN installation.
Figure 2: WFA100-SN Features
Figure 3: WFA100-SN Terminals
Line voltage wiring connects to the electrical supply circuit
andtotheballast(s).Lowvoltageterminalsprovideconnections
for0-10VDCdimmingcontrolsignalstodimmingballasts.
The WFA100-SN low voltage terminals also supply low voltage
power and carry control signals from low voltage occupancy
sensors and photocells.
WhiletheWFA100-SNisinInstallationTestmode,thelowvoltage
devices directly control the lights wired to the same WFA100-SN.
AfteryouexitInstallationTestmode,thelightsturnOnandare
NOTcontrolledbythedevicesconnectedtotheWFA100-SN.
Afterjoiningthewirelessnetwork,thecontrolsignalsfromthe
low voltage devices pass through the WFA100-SN and are sent
wirelesslytoDaintreeNetworked.Dependingonthezoneand
devicecongurationinDCS,wirelesssignalsfromtheWACto
the WFA100-SN determine operation of the light(s).
Design Caution
Do not install a wireless adapter such as the WFA100-SN to
control an electrical circuit that provides power to other wireless
devices or adapters. If power to wireless adapters or devices is
shutoff,controlandcommunicationwiththemisdisabled.
Reducing noise on low voltage (0-10V) wiring
• Keep wiring as short as practical
• Keep signal lines separate from mains voltage
lines.
• Reducetheareacreatedbythesignallinesand
 theGNDreturn(i.e.,keepthemclosetogether).
• IfpossibletwistthesignallinewiththeGNDreturn.
Must be installed inside a light xture, or in an
enclosure to protect people from high voltage.
Risk of electrical shock. Disconnectallpowerbeforeinstallation.
Allinstallationandmaintenanceoflinevoltageequipmentmustbe
performedbyaqualiedelectrician.TheWFA100-SNmustbeinstalled
inaccordancewithalllocal,state,andnationalelectricalcodesand
requirements.Wiringconnectorsarenotsupplied.ULrecognizedwiring
connectorsmustbeusedintheinstallation.Eachterminalcanaccept
one conductor only. Connect only one 4AWG to 16AWG (0.2-1.5 mm)
wire to any terminal.
CLASS 2 WIRING:
AlleldwiringshallbesuitableforClass1. Electric Light
andPower,orClass2,3wiringsareroutedseparately
andsecuredtomaintainseparationbetween:
1. Class2wiringandallotherclasswiring,and
2. Limited energy circuit conductors from unlimited
energy circuit conductors.
CAUTION
