Installation GuideDaintree

Networked Wireless Fixture Adapter (WFA100-SN)

Figure 4: Dimming Ballasts

Figure 5: On/Off (non-dimming) Ballasts

Perform Installation Test Suite 1

Wiring Continued

Remove the jumper from the violet and gray terminals

beforeconnectingthe0-10Vdimmingcontrolwires.
