Daintree GE Current WFA100-SN - Page 4

Installation GuideDaintree
®
Networked Wireless Fixture Adapter (WFA100-SN)
4
Figure 6: On/Off (non-dimming) Ballast(s), Occupancy
Sensor conguration
Figure 7: Dimming Ballast(s), Occupancy Sensor conguration
Figure 5: On/Off (non-dimming) Ballasts
Perform Installation Test Suite 2
3
Wiring Continued
ThiscongurationallowstheWFA100-SNtoprovideautomatic
On/Offswitchingofballastsandprovidesanoccupancysensor
input. Set the occupancy sensor for the minimum time delay.
ThiscongurationallowstheWFA100-SNtoprovideautomatic
0-10VdimmingcontrolandtoswitchballastsOn/Off.Italso
provides an occupancy sensor input. Set occupancy sensor for
minimum time delay. Remove the jumper from the violet and
gray terminals before connecting the 0-10V dimming control
wires. Remove the jumper from the blue and gray terminals
before connecting the occupancy sensor wires.
Perform Installation Test Suite 2
