ENGLISH
100
Cleaning the air filter
Duct and Ceiling Type
1- Open the air-in grill
Push the grill switches towards the middle simultaneously as indicated in follow figure sketch.
Then pull down the air-in grill.
2- Take out the air-in grill.
3- Dismantle the air filter
4- Clean the air filter (Vacuumcleaner or pure water may be used to clean the air filter. If the dust accumulation is too heavy ,
please use soft brush and mild detergent to clean it and dry out in cool place) .
•
The air-in side should face up when using vacuum cleaner. (See Fig. 1)
•
The air-in side should face down when using water. (See Fig. 2)
5- Re-install the air filter.
6- Install and close the air-in grill in the reverse order of step 1 and 2 and connect the control box cables to the corresponding
terminators of the main body .
Note: High-static Pressure Parvis Split Type has no air filter.
MAINTENANCE
CAUTIONS: The control box cables ,which are originally connected with the main body
electrical terminators must be pulled off before doing as indicated above.
Fig. 1 Fig. 2
CAUTIONS: Do not dry out the air filter under direct sunshine or with fire.
Clip
Open
