IDENTIFICATION PARTS
NAMES OF PARTS
Front
Rear
1. Operation panel
2. Horizontal louver blade (swing automatically)
3. Caster
4. Carrying handle (both sides)
5. Upper air lter (Behind the grille)
6. Upper air intake
7. Air outlet
8. Drain outlet (only for Pump heating model)
9. Power cord outlet
10. Power cord buckle
(Used only when storing the unit)
12. Bottom tray drain outlet
13. Power plug socket
(Use only when storing the unit)
Lower air lter (Behind the grille)
14. Lower air intake
15. Drain outlet
Fig. 1
Fig. 2
To Next Page
