ENGLISH
100
PARTS NAMES
Indoor unit
1- Room temperature sensor.
2- Front panel.
3- Air inlet.
4- Air filter.
5- Air outlet.
6- Vertical air flow louver.
7- Horizontal air flow grille.
8- Display panel.
9- Infrared signal receiver.
10- Remote Controller.
11- Control panel.
Outdoor unit
12- Drain hose, refrigerant connecting pipe
and electric wiring.
13- Air inlet (side and rear).
14- Air outlet.
Display panel
The operating conditions are indicated below:
1 Operation Lamp
2 Automatic Lamp
3 Timer Lamp
4 Economic Lamp
5 Pre-defrost Lamp
(Cooling only type without).
6 Infrared signal receiver
10 cm or more
60 cm or more
100 cm or more
60 cm or more
Air outlet
4.5 cm or more
Indoor unit
Indoor unit
Outdoor unit
Display panel
ASD9U2eng 17/7/08 09:53 Página 100
