MAINTENANCE
Before you clean the air conditioner be sure to disconnect
the power suppiy plug.
Cleaning the air filter
1. Pull up from two ends of panel. Open the panel and lift
the panel up to an angle where it remains fixed. Do not lift
the panel any further when it stops with a clicking sound.
2. Take hold of the left and right handles of the air filter and
lift it up slightly to take it out from the filter holder.
3. Take hold of the handles and pull the air filter down-
ward.
4. Remove the AIR FILTER from the indoor unit.
• Clean the AIR FILTER from the indoor unit.
• Clean the AIR FILTER with a vacuum clearer or water,
then dry it up in cool place.
*5. Remove the ACTIVE CARBON FILTERIELECTRO from
the indoor unit and take it out from its support frame.
• Clean the filter every month, immerse the filter in the
water with the mild detergent for 20 minutes and wash it
slightly (do not rub), then expose it in the sun to dry it out for
more than 3 hours. (put the black side face up)
6. Install the filters into their support frames and set the
support frames back in position. The black side of the fil-
ters be at the outsides.
7. Insert the AIR FILTER from the top side into the unit until
it is fixed thoroughly and ciose the front panel of the indoor
unit tightly.
* Optional filter
