ENGLISH
60
(6) Unit stop
Press ON/OFF button.
Only time remains on LCD.
All indicators on indoor unit go out.
Vertical flap closes automatically.
Hints
As cold air flows downward in COOL mode, adjusting air flow horizontally will be much more helpful for a better air circulation.
As warm air flows upward in HEAT mode, adjusting air flow downward will be much more helpful for a better air circulation.
Be careful not to catch a cold when cold air blows downward.
It is harmful to your health in summer to go frequently in and out of places where temp. difference is above 7ºC. Temp. diffe-
rence of 3-5ºC will remove your fatigue.
More than this, unit's load can be reduced and power consumption cut down as well. So, you'd better set a temp. difference
of 3-5ºC between indoor and outdoor temp. in COOL mode.
Cautions:
When humidity is high, condensate water might occur
at air outlet if all horizontal louvers are adjusted to left
or right.
Cautions:
Unit won't restart until 3 minutes have elapsed, due to
system protection. HEAT mode is not available cooling
only unit.
COOL
About 10º
About 10º
COOL About 45º
HEAT About 60º
HEAT
About 60º
OPERATION
Left and right air flow adjustment (manual)
Move the horizontal blade by a knob on air conditioner to
adjust left and right direction referring to Fig.
Up and down (Use remote controller)
Press SWING button, vertical flap will move within the range
shown in the Fig. Press SWING button stop it at a fixed posi-
tion.
(5) Air flow direction adjustment
After operation mode is selected, vertical flap will open automatically according to the mode.
Referring to the Fig.
Cautions:
It is advisable not to keep vertical flap at downward posi-
tion for a long time in COOL or DRY mode, otherwise,
condensate water might occur.
MUsECO410DaEng 16/11/07 13:52 Página 60
