Dali Katch One User Manual

7.6 HDMI IN
Connect a TV to the DALI KATCH ONE using HDMI ARC.
ARC
✓
This connection requires that the DALI KATCH ONE is
connected to your TV’s HDMI ARC input, that CEC is turned
on (will be described later), and that you select alternative
audio output in the TV’s audio menu. Also the audio output
must be set to Stereo or PCM. The correct menu and
wording will differ between TV brands. Please refer to your
TV manual for the correct settings on your TV.
If your TV do not support HDMI ARC, DALI recommend using an Optical
connection to the DALI KATCH ONE (See 7.5). In this case it is still possible
to simultaneously use the HDMI connection to enable the TV remote
control for use with the KATCH ONE using the CEC function (See below).
To enable the use of your TV remote over HDMI to control basic functions
(volume, mute power on/off) your TV needs to have HDMI CEC enabled.
HDMI CEC has different names depending on the TV brand:
• Samsung: Anynet+
• LG: SimpLink
• Sony: Bravia Link
• Phillips: EasyLink
• Panasonic: Viera Link
• Hitachi: HDMI-CEC
14
7.0 CONNECTIONS

Dali Katch One Specifications

General

Subwoofer included	No
Certification	CE, FCC
Product color	Black
Wall mountable	Yes
Cables included	AC
Receiver included	-
Bluetooth version	4.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Digital audio optical in	2
RMS rated power	200 W
Audio output channels	- channels
Tweeter diameter	21 mm
Crossover frequency	2500 Hz
Number of woofer drivers	4
Woofer diameter (imperial)	3.5 \
Signal-to-Noise Ratio (SNR)	100 dB
Magnet type	Neodymium
Soundbar frequency range	46 - 25000 Hz
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	69 mm
Width	860 mm
Height	164 mm
Soundbar weight	3700 g
