EXAMPLE: VERSION 1.1
EXAMPLE: VERSION 2.5
Flash 1: Flash 2: Flash 3:
SUM = 1 . SUM = 1
9.3 FIRMWARE - READOUT
CURRENT VERSION
4
8
2
1
Flash 1: Flash 2: Flash 3:
SUM = 2 . SUM = 1+4 = 5
“.”
First digit(s)
Last digit(s)
17
9.0 FACTORY RESET & FIRMWARE UPGRADE
FLASH 2:
FLASH 1:
FLASH 3:
Initiate factory reset (See 9.1) to read
out current firmware version.
The current firmware version is
automatically shown by an indicator
light sequence. It is interpreted by the
sum of the indicator lights using the
following format:
