Dali SOUND HUB COMPACT User Manual

3. Installation and Setup
• To switch the SOUND HUB COMPACT from
standby mode to operational mode, press the
remote control Standby buon, or any of the
source select buons. The LED indicators on the
SOUND HUB COMPACT top panel will illuminate
according to the volume level. When changing
source a single LED will illuminate according to
the chosen input. The top panel indicators are
illustrated in Diagram 6.
NOTE:
If your SOUND HUB COMPACT has been
previously used it may need to be reset. To reset
your SOUND HUB COMPACT use an appropriate
tool to press and hold the rear panel RESET
pinhole buon for 1second. The location of the
reset buon is illustrated in Diagram 7.
