» TOKENS PRESENT:
(Visible and programmable only if „MDB coin return‟ payment system that foresees the “Token” function is installed)
To read the number of tokens present in the MDB payment system tubes, and to enable or disable
recognition of these tokens:
“n” number of the token,
“xxx” number of tokens in the tube, if the tube is not enabled it displays “---“,
“yyy” =ON token enabled, =OFF token disabled
Press the C key to empty the tube manually
> BANKNOTES AND STACKER:
If there is an MDB banknote reader installed in the vending machine, the reading and/or recognition of the
quantity and/or value of banknotes or tokens present in the MDB payment system will be possible.
The following banknote and stacker parameters can be set by selecting this function.
» BANKNOTES PRESENT:
(Visible and programmable only if an “MDB banknote reader” is installed)
To read which and how many banknotes are present in an MDB payment system and to enable
recognition of them:
“nn” number of the banknote, “vvvvv” value of the banknote
“Secur.H” recognition security level high, “Secur.L” low
“Enabl.ON” banknote enabled, “Enabl.OFF” banknote disabled
Press F to enable/disable the banknote; press C to change the recognition security level.
Note 1: The value of the banknotes recognised by the payment system depends on the system itself;
refer to the relative documentation.
Note 2: the meaning and operation of the recognition security level depends on the payment system;
refer to the relative documentation.
» TOKEN
(Visible and programmable only if an “MDB banknote reader” that foresees the “Token” function is installed)
To enable the token recognised by an MDB banknote reader:
“Secur.H” recognition security level high, “Secur.L” low
“Enabl.ON” token enabled, “Enabl.OFF” token disabled
Press C to change the recognition security level.
Press the F key to enable/disable the token.
Note 1: the meaning and operation of the recognition security level depends on the payment system;
refer to the relative documentation.
Programming
MDB parameter
Coins and tubes
->->->
Token: n
In tubes xxx yyy
F
F
Programming
MDB parameter
Banknote stacker
->->->
Bill nn vvvvv
Secur.H Act.ON
F
F
Programming
MDB parameter
Banknote stacker
->->->
* Token * vvvvv
Secur.H Act.ON
F
F
