damian LXS9 Series User Manual

Serie "LXS9"
Pagina A - 19
Rev. M - 01
> SLIDING PANEL TEST
Select this item to perform the sliding anti-theft panel operation test.
When the following message appears on the display:
Parameter O  Panel open microswitch X = 1 pressed X = 0 not pressed.
Parameter C  Panel closed microswitch Y = 1 pressed Y = 0 not pressed
Press the 1 key to open the anti-theft panel.
Press the 2 key to close the anti-theft panel.
If automatic calibration of time/speed of opening/closing of the sliding panel is needed press 9 key for 2
seconds, the sliding panel will perform some opening/closing cycles:
At the end of the test, the following message will appear on the display:
Press any key to quit the test.
If a diagnosis of the sliding panel motor is needed, press 8 key for 2 seconds: the sliding panel will
perform some opening/closing cycles.
At the end of the test the following message will appear on the display:
X and Y values equal or superior to 5 induce a good efficency of the motor.
X and Y values inferior to 5 induce a low efficency of the motor.
Motor works as well, but it is necessary to make the following controls in order to avoid future demages:
Check that the sliding panel can slide freely, that guides are clean and that there is nothing that reduces
the sliding speed, eventually provide to lubricate sliding panel rack and pinion.
If repeating the test one of X and Y values is still less than 5 it is advisable to provide replacement of the
motor in a short time.
Press the A key to exit the submenu.
> “PUSH” PRODUCT REMOVAL DOOR TEST
Select this item to perform the “Push” product removal door operation test.
When the following message appears on the display:
Press the F key to unlock the “Push” product door for 10 seconds.
Press the F key again to relock the “Push” product door.
O C ADC Ttot TAp
X Y zzz zzzz zzz
CL LK ADC OUT F
X Y ZZZ Z Z
Programming
Diagnostics
Anti-tft p. test
->->->->
O C ADC Ttot TAp
X Y zzz zzzz zzz
F
F
Programming
Diagnostics
Test block Push
->->->->
CL LK ADC OUT F
X Y ZZZ Z Z
F
F
O:xxx C:xxx Pxxx
TO:xxxx TC:xxxx
Open:X zzzz zzzz
Clos:Y zzzz zzzz
