KEY PAD FUNCTIONS
Cool Mode:
Illuminates while the unit
is operating in air conditioning mode.
Fan Only Mode:
Illuminates while unit
is operating in ‘Fan Only’ mode.
Dehumidifier (Dry) Mode:
Illuminates
while the unit is operating in dehumidi-
fication mode.
MODE INDICATOR LIGHTS
STATUS DISPLAY
Low Fan
Medium Fan
FAN SPEED INDICATOR LIGHTS
High Fan
AUTO-ON: Signifies the auto-
on
timer
setting has been initiated.
Water Full: Illuminates to indicate that
the inter water tank is full and will have
to be emptied.
TEMPERATURE DISPLAY: Displays
current ambient room (fan mode only)
or set temperature in Celsius or
Fahrenheit scale.
Fahrenheit:
Signifies the temperature
is currently displayed in Fahrenheit.
AUTO-OFF: Signifies the auto-
off
timer
setting has been initiated.
POWER SWITCH: Turns unit On /
MODE : Allows you to scroll through
and select the desired operating
mode.
FAN : Select from three different fan
settings;
High Medium and Low.
AUTO-TIMER Adjust :
TIMER-ON: Used to initiate the AUTO-
ON (start) timer and adjust Timer On
settings
forward
(0.5 hour increments).
TIMER-OFF: Used to initiate the
AUTO-OFF (stop) timer and adjust
Timer Off settings
forward
(0.5 hour
TEMPERATURE Adjust:
Continually depress to adjust tempera-
ture settings forward (1°C / °F incre-
ments).
Continually depress to adjust tempera-
ture settings
backward
(1°C / °F incre-
ments).
Note
: This appliance allows you to select the tem-
perature scale to be displayed in either the “Celsius”
or Fahrenheit” according to your preference.
To change temperature scale displayed on the con-
trol panel display, press and hold and arrow
buttons simultaneously to alternate between the
“Celsius” & “Fahrenheit” scale.
7
