15. TECHNICAL SPECIFICATIONS
INPUTS
Mic input balanced 2 kOhm. Plus 48volt phantom
Mic noise -122 dBr (A-weighted).
Sensitivity: -70dB min, 0dB maximum.
Line inputs: unbalanced, 10kOhm, Cinch gain range 40dB.
Phono inputs: unbalanced, 47kOhm, 1-10 mV.
2 Track return: -10dBv at 10kOhm.
Aux return: -10dBv at 10kOhm.
HYBRID
Output : Internally connected in the Airmate.
Input : Line level 0 dBu balanced, internally connected in the Airmate.
R/C balance : fully adjustable
Separation : more than 30dB. (dependent upon adjustments of RC balance)
OUTPUTS
Left/Right/Monitor/Aux: +4dBu (1.55volt) at 47 Ohm.
Tape output: -10dBv at 1kOhm.
Headphone: 400-600 Ohm, 500mW.
EQUALIZER
High: +/- 12 dB at 12kHz shelving curve.
Mid: +/- 12 dB at 1 kHz bell curve.
Low: +/- 12 dB at 60 Hz bell curve.
RED LIGHT Stereo jack connector to intern relay
Center Contact = Tip
Normally Closed = Shield
Normally Open = Ring
OVERALL
Frequency response 10-60.000 Hz (+/- 0.5dB).
Distortion: <0.009% max at 1 kHz.
Power consumption: 25VA
Dimensions : 483 x 356 x 95 mm ( 8HE ).
: (19” x 14” x 3.74”)
Weight : 11 kg. (24.4 lbs.)
DROP THROUGH
Drop through hole to be cut needs to be 450x330mm
Depth of mixer is 95mm
We wish you many creative years of productivity using this quality product from:
D&R Electronica Weesp b.v.
Rijnkade 15B
1382 GS WEESP,
The Netherlands
Phone: 0294-418 014
Fax: 0294-416 987
Website: http://www.d-r.nl
E-mail: info@d-r.nl
