UNPACKING THE QuicKART 2000
1) The QuicKART 2000 is typically shipped on a wooden pallet. It comes with
additional components packaged inside the QuicKART. Care must be taken not to
damage them during the unpacking. The components are:
a) QuicKART, the basic electric machine with two keys,
b) A box including: a Remote Control Transmitter, to remotely control the
QuicKART, and Cart Coupler Hardware (yokes for the cart coupler).
2) Remove all the plastic film that is wrapped around the system components. Take
care not to bend beacon post components (especially the antennas) when removing
the plastic. Cut banding material, which holds the QuicKART to the pallet.
3) Raise the hood to find a small box containing the remote control, and cart coupler
hardware. Remove this box and set it aside.
4) To remove the QuicKART from the pallet, use a sturdy wooden board(s) to create a
ramp. Remove all straps holding the QuicKART to the shipping pallet. Insert the key
and turn on the QuicKART. Turn the twist grip slowly and guide the QuicKART
forward, down the ramp to the floor.
5) Turn OFF the QuicKART.
6) Make sure the machine is OFF, the Beacon post hinges from a center position on a
bolt and nut already installed. Swing it to an 11:00 o’clock position. Remove the bolt
at the bottom of the beacon post bracket. Replace the bolt in the bottom holes and
tighten lightly. Use care not to damage the wires. Take care not to damage the
antenna, lights or the cable connectors at the ends of this beacon post.
7) To attach the cart coupler yokes, refer to the diagrams starting on page 22 of the
Owner’s Manual.
8) Each hand-held remote control transmitter operates on a unique pre-programmed
code. For the QuicKART to operate in the Remote Mode, the receiver, which is in
the beacon post, must be programmed to match the hand held transmitter. See
page 39 for directions on how to program the remote control transmitter.
