Dane Technologies, Inc. QuicKART 2000 Owner’s Manual
7105 Northland Terrace, Minneapolis, MN 55428 / 888-544-7779 / 763-544-7779 / Fax 763-544-4234
www.danetechnologies.com 970-026 rev 3-1-06
43
CHANGING REAR TIRE
REAR CASTERED TIRE:
Turn QuicKART off and remove key.
QuicKART must be on a flat surface. Make sure the automatic brake is functional and on.
Use protective eyewear at all times.
1) Lift the back of the QuicKART so the rear castered wheel is approximately 2 inches
off the ground. This is accomplished by using a jack under the rear frame of the
QuicKART, in the center. Once the QuicKART is lifted, place a sturdy and stable
block in each corner then lower the jack so the weight of the QuicKART is resting
on the blocks. Also place blocks on the front wheels to keep the QuicKART from
rolling.
2) With two 9/16” wrenches, remove the four bolts holding the caster assembly to the
frame. Save the hardware and use it when replacing the wheel.
3) When replacing the caster assembly, reuse the saved hardware. Insert bolts,
apply nuts and tighten.
4) Using the jack, lift the QuicKART off the supporting blocks (Item #1 above),
remove the blocks then lower the QuicKART to the ground.
Note: Variations in the hardware configuration may occur. Save all hardware and
use it as it was removed when replacing wheel.
