Dane Technologies, Inc. QuicKART 2000 Owner’s Manual
7105 Northland Terrace, Minneapolis, MN 55428 / 888-544-7779 / 763-544-7779 / Fax 763-544-4234
www.danetechnologies.com 970-026 rev 3-1-06
42
CHANGING FRONT TIRES
FRONT DRIVE TIRES:
Turn QuicKART off and remove key.
QuicKART must be on a flat surface. Make sure the automatic brake is functional and on.
Use protective eye wear at all times.
1) Slightly loosen the four (4) lug nuts, about 1/2 turn, from the wheel needing
service. Use a 9/16-inch socket. IMPORTANT: Do not remove any of the nuts;
only slightly loosen them while the wheel is still on the ground.
2) Use a jack to lift the front of the QuicKART off the ground approximately 2 to 3
inches. Insert a sturdy and stable block under the frame to hold it securely in this
elevated position.
3) Unscrew the four 9/16-inch, front wheel lug nuts and place them in a location
where they will not become lost. Remove the wheel. The new or repaired wheel is
placed back on the front hub with the tire stem facing out. Replace the 4 lug nuts
with the beveled side toward the inside and tighten.
4) Using the jack, lift the QuicKART off the supporting block (see item #2 above).
Remove the block and use the jack to lower the QuicKART to the ground. Tighten
the 4 lug nuts again ensuring that they are tightened to a minimum of 50 foot-
pounds torque.
