Instruction CF-RF Room Thermostat with InfraRed Floor Sensor
1. Functional Overview
Front - g. 1
Up/down selector
Push button
Red LED (behind the cover)
InfraRed oor sensor
LED modes
Permanent light ON
No light OFF
Slow ashing Flashes
Fast ashing Flickers
Back - g. 2
Back plate
Back plate lock/unlock (turn 90°)
Screw hole for wall mounting
Battery placement
Screw and wall plug
