DANFOSS
RANDALL
103E7
LOAD
MAINS SUPPLY
(via 3 amp fuse)
An additional terminal block is
required where these discon-
nected leads (or pairs of leads)
should be terminated
ON SPARE COM
1 2 3 5 (N) 6 (L) A B C D
RANDALL 103, 103E,
103E7
123 56
RANDALL 3020 4 2 - 1,7 6 3 5
RANDALL TSR2 5 4 1 3 2 6 7
GRASSLIN 45, 45A, 45E 4 - 3 2 1
HORSTMANN 424
EMERALD & PEARL
AUTO RANGE
423 NL,15
HORSTMANN 423
PEARL, EMERALD &
TOPAZ
413 NL256
SANGAMO S254 Form 2,
S408 Form 5,
S251 Form 2
LOAD - - N L
SANGAMO S610 F2,
S611 F2, S612 F2, S408
F4, S408 F6, S253 F2,
S255 F2
LOAD -
SWITCH
LIVE
N
MOTOR
LIVE
