■ Parameter list VLT 5000 Flux
Data
type
PNU Parameter Factory setting Range Changes Conversion
# description during Index
operation
001 Language English Yes No 0 5
002 Local/remote control Remote control Yes Yes 0 5
003 Local reference 000.000 Yes Yes -3 4
004 Active setup Setup 1 Yes No 0 5
005 Programming setup Active setup Yes No 0 5
006 Copying of setups No copying No No 0 5
007 LCP copy No copying No No 0 5
008 Display scaling speed 1 0.01 - 100.00 Yes Yes -2 6
009 Display line 2 Speed [Rpm] Yes Yes 0 5
010 Display line 1.1 Reference [%] Yes Yes 0 5
011 Display line 1.2 Motor current [A] Yes Yes 0 5
012 Display line 1.3 Power [kW] Yes Yes 0 5
013 Local operation mode LCP control Yes Yes 0 5
014 Local stop Enable Yes Yes 0 5
015 Local jog Not possible Yes Yes 0 5
016 Local reversing Not possible Yes Yes 0 5
017 Local reset of trip Possible Yes Yes 0 5
018 Lock for data change Not locked Yes Yes 0 5
019 Operating state at Forced stop, use saved ref. Yes Yes 0 5
power-up, local control
024 Userdefined Quick Menu Not active Yes No 0 5
025 Quick Menu Setup 000 0-999 Yes No 0 6
100 Configuration Speed control, closed loop No Yes 0 5
101 Torque characteristics High - constant torque Yes Yes 0 5
102 Motor power Depends on the unit 0.18-500 kW No Yes 1 6
103 Motor voltage Depends on the unit 200 - 575 V No Yes 0 6
104 Motor frequency 50 Hz No Yes 0 6
105 Motor current Depends on the unit 0.01- I
VLT;MAX
No Yes -2 7
106 Rated motor speed Depends on the unit 100-60000 rpm No Yes 0 6
107 Automatic motor adaptation, AMA Adaptation off No No 0 5
119 High starting torque 0.0 sec. 0.0 - 0.5 s Yes Yes -1 5
120 Start delay 0.0 sec. 0.0 - 10.0 s Yes Yes -1 5
121 Start function Coasting in start delay time Yes Yes 0 5
122 Function at stop Coasting Yes Yes 0 5
123 Min. speed for activating 0.0 rpm 0 - 600 rpm Yes Yes -1 5
function at stop
124 DC holding current 50 % 0 - 100 % Yes Yes 0 6
125 DC braking current 50 % 0 - 160 % Yes Yes 0 6
126 DC braking time 10.0 sec. 0.0 - 60.0 sec. Yes Yes -1 6
127 DC brake cut-in frequency Off 0.0-par. 202 Yes Yes -1 6
128 Motor thermal protection No protection Yes Yes 0 5
129 External motor fan No Yes Yes 0 5
130 Start speed 0.0 rpm 0.0-600 rpm Yes Yes -1 5
131 Initial current 0.0 Amp 0.0-par. 105 Yes Yes -1 6
150 Stator resistance Depends on unit Ohm No Yes -4 7
151 Rotor resistance Depends on unit Ohm No Yes -4 7
152 Stator leakage reactance Depends on unit Ohm No Yes -3 7
153 Rotor leakage reactance Depends on unit Ohm No Yes -3 7
154 Main reactance Depends on unit Ohm No Yes -3 7
156 Pole number 4-pole motor 2-100 No Yes 0 5
158 Ironloss resistance 10000Ω 1-10000Ω No Yes 0 6
161 Minimum inertia Depends on unit Kgm
2
No Yes -4 7
162 Maximum inertia Depends on unit Kgm
2
No Yes -4 7
4-Setup
Parameter list
