Danfoss 5000 Flux - Page 54

MG.90.D1.02 – VLT is a registered Danfoss trademark
54
VLT
®
5000/5000 Flux/6000 HVAC/8000 AQUA PROFIBUS
■■
■■
■ Parameter list VLT 8000 AQUA
Conversion
index
0
0
-1
0
-1
-1
0
2
0
0
0
0
0
-3
-3
-1
0
0
-3
-3
0
0
-1
-2
-2
-2
-1
-2
74 (?)
?
PNU Parameter Factory setting Range Changes 4-Setup Data
# description during operation type
400 Reset function Infinate Automatic Yes Yes 5
401 Automatic restart time 10 sec. 0 - 600 sec. Yes Yes 6
402 Flying start Enable Yes Yes 5
403 Sleep mode timer Off 0 - 300 sec. Yes Yes 6
404 Sleep frequency 0 Hz f
MIN
- Par. 405 Yes Yes 6
405 Wake up frequency 50/60 Hz Par. 404 - f
MAX
Yes Yes 6
406 Boost setpoint 100% 1 - 200 % Yes Yes 6
407 Switching frequency Depends on the unit 3.0 - 14.0 kHz Yes Yes 5
408 Interference reduction method ASFM Yes Yes 5
409 Function in case of no load Warning Yes Yes 5
410 Function at mais failure Trip Yes Yes 5
411 Function at overtemperature Trip Yes Yes 5
412 Trip delay overcurrent, I
LIM
60 sec 0 - 60 sec. Yes Yes 5
413 Minimum feedback, FB
MIN
0.000 -999,999.999 - FB
MIN
Yes Yes 4
414 Maximum feedback, FB
MAX
100.000 FB
MIN
- 999,999.999 Yes Yes 4
415 Units relating to closed loop % Yes Yes 5
416 Feedback conversion Linear Yes Yes 5
417 Feedback calculation Maximum Yes Yes 5
418 Setpoint 1 0.000 FB
MIN
- FB
MAX
Yes Yes 4
419 Setpoint 2 0.000 FB
MIN
- FB
MAX
Yes Yes 4
420 PID normal/inverse control Normal Yes Yes 5
421 PID anti windup On Yes Yes 5
422 PID start-up frequency 0 Hz f
MIN
- f
MAX
6
423 PID proportional gain 0.01 0.00 - 10.00 Yes Yes 6
424 PID start-up frequency Off 0.01 - 9999.00 s. (Off)Yes Yes 7
425 PID differentiation time Off 0.0 (Off) - 10.00 sec. Yes Yes 6
426 PID differentiator gain 5.0 5.0 - 50.0 Yes Yes 6
limit
427 PID lowpass filter time 0.01 0.01 - 10.00 Yes Yes 6
433 Motor alternation time 0 (OFF) 0 - 999 hrs Yes Yes 6
434 Motor alteration function Ramp Ramp/Coast Yes Yes ?
Parameter list
