6. How to I nstall Option in Frequency Converter
6.1.1. How to I nstall Option in Frequency Converter
Items required to install a fieldbus option in the frequency converter:
- The fieldbus option
- Fieldbus option adaptor frame for the AKD 102. This frame is deeper than the standard frame, to allow space for the fieldbus option beneath
- Decoupling plate (only for A1 and A2 enclosures)
Please refer to the section
How to I nstall
in this manual for connections.
130BT611.10
Please not e, for connection of screen, please refer to the graphic in section 4.1.1
The LonWorks Option
.
ADAP-KOOL
®
AKD-LonWorks
6. How to I nstall Option in Frequency Con-
verter
MG.11.P1.02
15
6
