Danfoss AFD - Page 5

© Danfoss | 2021.05 | 5AQ13418645844301-010402
AFD/VFG(S) 2(1)
①
①
④
⓯
②
⑤
③
⑧
⑦
⓰
L
H
B
VFG(S) DN 15-125
L
B
H
VFG DN 150-250
L
B
1
H
1
VFG(S) DN 150-250
with valve body extension
up to 200 (300) °C
A
H
AFD (32/80/250/630 cm
2
)AFD (160 cm
2
)
A
H
70
120
Comb. piece
KF2, KF3
78
110
SW 22
ø60
Shut off valve Compression
fitting
SW19
40
Ø10
G⁄
240
Ø 89
Seal pot V1
298
Ø 140
Seal pot V2
Valve stem
extension
D40
155
Valve stem
extension
ZF4, ZF5
180
95
Valve stem
extension
ZF6
⑥
SW 36
VFG 2, VFG 21, VFGS 2 Valves
DN 15 20 25 32 40 50 65 80 100 125 150 200 250
L
mm
130 150 160 180 200 230 290 310 350 400 480 600 730
B 213 213 239 239 241 241 276 276 381 381 326 354 401
H 267 267 304 304 323 323 370 370 505 505 505 591 661
B
1
mm -
620 852 1199
H
1
799
1089 1459
AFD Actuator
Actuator size cm
2
32 80 160 250 630
Ø A
mm
172 172 250 263 380
H 435 430 710 470 520
Weight kg 7. 5 7. 5 32.4 13 28
