Danfoss AK-PC 560 User Manual

14 Manual RS8GE202 © Danfoss 01-2016 AK-PC 560
Menu survey
SW: 1.0x
Fortsættes
Sequence
1. o61 must be set as the rst parameter. This parameter determines which of the four operating interfaces (application mode) are
activated. This must be set via the display keys. It cannot be set via data communication. (Active functions are shown below in shaded
elds.)
2. Quick- start
To get the system up and running quickly so that cooling can be commenced, start it by setting the following parameters (these pa-
rameters can only be set when the regulation is stopped, r12=0): r23, r28, c08, c16, c29, o06, o30, o75, o76 and nally r12=1.
3. Once the regulation is under way, you can go through the other parameters and adjust them in situ.
Function
Para-
meter
o61 =
Min. Max. Factory
setting
1 2
Normal display
Shows P0 in EKA 165 (display with buttons) - °C P °C / bar
Shows Pc in EKA 163 - °C P °C / bar
P0 reference
Neutral zone r01 0.1°C / 0.1 bar 20°C /5.0 bar 4.0°C / 0.4 bar
Correction of signal from P0 sensor r04 -50°C /-5.0 bar 50°C / 5.0 bar 0.0
Select view; SI or US. 0=SI (bar /°C), 1=US (Psig /°F) r05 0 1 0
Start/Stop of regulation
r12 OFF ON OFF
Reference oset for P0 (see also r27) r13 -50°C / -5.0 bar 50°C / 5.0 bar 0.0
Set regulation set point for P0 r23 -99°C / -1 bar 30°C / 60.0 bar 0.0°C / 3.5 bar
Shows total P0 reference
( r23 + various displacements)
r24 °C / bar
Limitation: P0 reference max. value
(also applies to regulation with reference displacement)
r25 -99°C / -1.0 bar 30°C / 60.0 bar 30.0°C / 40.0 bar
Limitation: P0 reference min. value
(also applies to regulation with reference displacement)
r26 -99°C / -1.0 bar 30°C / 40.0 bar -99.9°C / -1.0 bar
Displacement of P0 (ON=active “r13”) r27 OFF ON OFF
Pc reference
Set regulation set point for Pc r28 -25°C / 0.0 bar 75°C / 110.0 bar 35°C / 15.0 bar
Shows total Pc reference r29 °C / bar
Limitation: Pc reference max. value r30 -99.9°C / -0.0 bar 99.9°C/ 130.0bar 55.0°C / 60.0 bar
Limitation: Pc reference min. value r31 -99.9°C / 0.0 bar 99.9°C / 60.0 bar -99.9°C / 0.0 bar
Correction of signal from Pc sensor r32 -50°C / -5.0 bar 50°C / 5.0 bar 0.0
Pc reference variation. 1 and 2 are PI-regulation
1: Fixed reference. “r28” is used
2: Variable reference. Outdoor temperature (Sc3) included in the refer-
ence
3: As 1, but with P-regulation (Xp-band)
4: As 2, but with P-regulation (Xp-band)
r33 1 4 1
Reference oset for Pc r34 -50°C / -5.0 bar 50°C / 5.0 bar 0.0
The mean temperature dierence across the condenser at maximum
load (dim tm K)
r35 3.0 50.0 10.0
The mean temperature dierence across the condenser at the lowest
relevant compressor capacity (min tm K)
r56 3.0 50.0 8.0
Capacity
Min. ON time for relays c01 0 min 30 min. 0
Min. time period between cutins of same relay c07 2 min. 60 min 2
Denition of regulation mode
1: Sequential (step mode / FILO)
2: Cyclic (step mode / FIFO)
c08 1 2 1
Denition of compressor connections.
See options on page 11.
c16 1 7 1
Denition of condenser:
1-8: Total number of fan relays or voltage step on the voltage output
9: Only via analog output and start of frequency converter
10: Not used
11- 18: Total number of fan relays which are to be connected with alter-
nating start-up.
c29 0/OFF 18 0
Cut in compressor capacity with manual control. See also “c32” c31 0% 100% 0
Manual control of compressor capacity (when ON, the value in “c31” will
be used)
c32 OFF (0) ON (1) OFF (0)
