Liquid Level Sensor, AKS 4100/4100U
Ordering AKS 4100/4100U Cable version - AKS 4100/4100U
Description Code number
With HMI
Code number
Without HMI*
AKS 4100 with 5 m (197 in.) Ø2 mm (Ø0.08 in.) stainless
cable and counterweight
084H4501 084H4500
AKS 4100U with 5 m (197 in.) Ø2 mm (Ø0.08 in.) stainless
cable and counterweight
084H4521 084H4520
Description Probe length Code number
With HMI
Code number
Without HMI*
mm in.
AKS 4100 - Coaxial 500 084H4510 084H4503
AKS 4100 - Coaxial 800 084H4511 084H4504
AKS 4100 - Coaxial 1000 084H4512 084H4505
AKS 4100 - Coaxial 1200 084H4513 084H4506
AKS 4100 - Coaxial 1500 084H4514 084H4507
AKS 4100 - Coaxial 1700 084H4515 084H4508
AKS 4100 - Coaxial 2200 084H4516 084H4509
AKS 4100U - Coaxial 19.2 084H4530 084H4524
AKS 4100U - Coaxial 30 084H4531 084H4525
AKS 4100U - Coaxial 45 084H4532 084H4526
AKS 4100U - Coaxial 55 084H4533 084H4527
AKS 4100U - Coaxial 65 084H4534 084H4528
AKS 4100U - Coaxial 85 084H4535 084H4529
Coaxial version - AKS 4100/4100U (available in predened lengths, with or without HMI)
Accessories
Description Code number
AKS 4100/4100U HMI Service/Display unit with rear cover and mounting bracket 084H4540
AKS 4100/4100U HMI Display 084H4548
Description Code number
AKS 4100/4100U Signal Converter without HMI, excluding cable gland 084H4541
Service kits
Description Content Code number
Cable and counterweight for
AKS 4100/4100U - CABLE version
Cable - 5 m (197 in.) Ø2 mm (Ø0.08 in.)
084H4542Crimp
Counterweight
End connector incl screws for
AKS 4100/4100U - COAXIAL version
End connector (incl. 3 mm (0.12 in)
set screws)
084H4549
Process connection, counterweight and
5 m (197 in.) Ø2 mm (Ø0.08 in.) cable for
AKS 4100 - CABLE and COAXIAL version
1in. process connection
084H4545
Counterweight
Process connection, counterweight and
5 m (197 in.) Ø2 mm (Ø0.08 in.) cable for
AKS 4100U - CABLE and COAXIAL version
3/4in. NPT process connection
084H4546
Counterweight
Description Code number
AKS 4100/4100U Coaxial tube. Tube length : 680 mm (26.8 in.) 084H4543
AKS 4100/4100U blank top cover for signal converter 084H4544
AKS 4100/4100U Aluminium gaskets (10 pcs.) for 1in. process connection 084H4547
AKS 4100 1. in. welding connection 027F1010
Other spare parts
* When ordering
without HMI
please observe:
Each AKS 4100/AKS 4100
must always be programmed
via the HMI display unit.
The HMI display unit can be
ordered separately and there
are two possibilities:
• 084H4540
AKS 4100/4100U HMI display
unit with rear cover and
mounting bracket.
The mounting bracket is
very useful when the AKS
4100/4100U have to be
programmed.
The same AKS 4100/4100U
HMI display unit can be used
to programme more AKS
4100/4100U and both Cable
and Coaxial versions.
• 084H4548
AKS 4100/4100U HMI display
unit (usually spare part).
