Instruction CF-RF Room Thermostat with Infrared Floor Sensor
strong articial light (e.g. halogen spotlight),
draught, other heat-emitting equipment (e.g. TVs)
etc. is avoided.
! Please note that no furniture, rugs etc. should be
permanently placed within the area of the InfraRed
Floor Sensor as shown in g. 3.
Mounting - g. 2
1. Mount the back plate
with the two screws
and wall plugs
via the screw holes in the
back plate
2. Slide thermostat into place on the back plate
3. If desired lock the thermostat to the back plate
with Allen key
(turn 90°)
6. Uninstallation
Activate Uninstall mode on Master Controller
- g. 1
• Use the Menu selection button
to choose
the Uninstall menu. Uninstall LED
ashes
• Activate Uninstall mode by pressing OK
.
Uninstall LED goes ON
Deselect output on Master Controller
• Select output to be removed by output selec-
tion button
• Remove ashing output with OK
