Danfoss ECL Comfort 210

MENU>Settings>Boiler
LowX
1x607
Definitionofwhichvoltagevaluecorrespondstowhichpositionvalue.
Thevoltage(asa0-10voltsignal)comesfromapositionmeasuringin
M1andisappliedtoinputS11(ECA32).Thisinputvoltageisconvertedto
displaya%valueforthepositionofM1.
Seealso"Position"and"HighX" .
SeeAppendix“ParameterIDoverview”
X
=
Volt
Y
=
Position
#1#
=
LowX
MENU>Settings>Boiler
HighX
1x608
Definitionofwhichvoltagevaluecorrespondstowhichpositionvalue.
Thevoltage(asa0-10voltsignal)comesfromapositionmeasuringin
M1andisappliedtoinputS11(ECA32).Thisinputvoltageisconvertedto
displaya%valueforthepositionofM1.
Seealso"Position"and"LowX".
SeeAppendix“ParameterIDoverview”
X
=
Volt
Y
=
Position
#1#
=
HighX
134|©Danfoss|2017.09
VI.GU.L2.02
OperatingGuideECLComfort210/296/310,applicationA275/A375
