ApplicationA375.2/A375.3(burnersteps7–8)
Terminal
Description
Max.load
5
Phaseforcontrolofburnersteps7and8
4
Connectionformotorizedcontrolvalve-opening,circuit2(A375.3)
0.2A/230Va.c.
3
Connectionformotorizedcontrolvalve-closing,circuit2(A375.3)
0.2A/230Va.c.
2
K7
Auxilliaryrelayforcontrolofburnerstep7
0.2A/230Va.c.
1
K8
Auxilliaryrelayforcontrolofburnerstep8
0.2A/230Va.c.
Wirecrosssection:0.5-1.5mm²
Incorrectconnectioncandamagetheelectronicoutputs.
Max.2x1.5mm²wirescanbeinsertedintoeachscrewterminal.
